This Paper Bottom Slitting Machine delivers high-precision cutting for 50–400g materials at speeds of 0–150m/min. It handles a maximum unwinding diameter of 1300mm and a finished roll diameter up to 850mm, with cutting width deviation of just ±0.3mm and end face deviation of ±0.5mm. The machine features a double rewinding shaft with a 3-inch air-expansion shaft, dual servo motor control for consistent roll tightness, and a 20kg magnetic powder tension system.
Rang of gram weight |
50-400g |
cutting width |
1200mm |
unwinding diameter |
<=1300mm |
Finished specification width |
1200 mm |
paper diameter |
<=800mm |
deviation of cutting width |
±0.3mm |
speed of operation |
0-150m/min |
suitable material |
60-400g |
