The fully automatic intelligent curling edge paper tray forming machine is a self-service forming machine with multiple workstations. It is a paper container forming equipment for producing paper coated paper, including pallets, square paper bowls, square paper cups, etc., which is controlled by a microcomputer servo system to automatically take out paper, perform hydraulic forming, roll edges, count and collect continuous processes.
Type |
JKB-600SF |
Paper Size |
300X250 （Different Size Mold Exchanged） |
Production Capacity |
13-18个/min（Actual output is based on product size) |
Suitable Material |
200-300g/m2 (PE Coated Paper,Greaseproof Paper,Silicon Coated Paper) |
Total Power |
6KW |
Total Weight |
0.7T |
Overall Dimension |
1700(L)*750(W)*1800(H)mm |
Gas Source Requirement |
Air pressure 0.5Mpa (Need to buy air compressor) |
Working Volume |
0.2-0.3 m3/min |
