The RY-950 is also designed with intelligent safeguards to protect print quality during interruptions. The rubber roller features an automatic breakaway function that activates during a machine stop. Additionally, the roller can be set to run at a low speed when idle, effectively preventing the ink from drying on the roller surface and saving significant cleanup time.
Printing speed |
60m/min |
Printing color |
4color |
Max web width |
950mm |
Max printing width |
840mm |
Max unwind diameter |
1100mm |
Max rewind diameter |
1100mm |
Printing girth |
250-580mm |
Overprint precision |
±0.15mm |
Voltage |
3 phase 380V, 50HZ |
Thickness of printing plate |
1.7mm |
Thickness of plate mounting tape |
0.38mm |
Diameter of air shafts |
76mm |
Dimensions |
3700*1920*2850mm |
Weight |
5100kg |
Power |
20kw |
